Rubber-metal holders

Rubber-metal dampers ,rubber-metal holders ,rubber-metal foots

•
•
•
•
•
•
•
•
•
•
•
•

Click for large image

We offer rubber holders with screws and nuts available in different sizes and threads. Depending on your need, we can manufacture holders with nuts or bols on both sides, as well as nut-bolt combinations.

The following tables list sizes of parts from our product list. If you need other sizes of rubber holders, feel free to contact us by phone or fill in the form Contact.

---

Rubber-metal holder (rubber holder - screw-screw)

No.	Name	A (mm)	B (mm)	C (mm)	D
1	Rubber metal holder	30	20	25	M6
2	Rubber metal holder	30	25	25	M6
3	Rubber metal holder	30	30	25	M6
4	Rubber metal holder	30	15	25	M8
5	Rubber metal holder	30	20	25	M8
6	Rubber metal holder	30	25	25	M8
7	Rubber metal holder	30	30	25	M8
8	Rubber metal holder	40	25	25	M8
9	Rubber metal holder	40	30	25	M8
10	Rubber metal holder	40	40	25	M8
11	Rubber metal holder	50	40	30	M10
12	Rubber metal holder	50	50	30	M10
13	Rubber metal holder	75	50	35	M12
14	Rubber metal holder	90	50	35	M14
15	Rubber metal holder	100	50	35	M16
16	Rubber metal holder	100	60	35	M16
17	Rubber metal holder	100	80	35	M16

We ship rubber-metal dampers with nuts, bolts and other parts.

Use: fan holders, vibrating assemblies, air conditioner holders, vibrating tables,
engine holders, exhaust pipe holders.

---

Rubber-metal holder (rubber holder screw-nut)

No.	Name	A (mm)	B (mm)	C (mm)	D
1	Rubber-metal holder	30	20	25	M6
2	Rubber-metal holder	30	25	25	M6
3	Rubber-metal holder	30	30	25	M6
4	Rubber-metal holder	30	15	25	M8
5	Rubber-metal holder	30	20	25	M8
6	Rubber-metal holder	30	25	25	M8
7	Rubber-metal holder	30	30	25	M8
8	Rubber-metal holder	40	25	25	M8
9	Rubber-metal holder	40	30	25	M8
10	Rubber-metal holder	40	40	25	M8
11	Rubber-metal holder	50	40	30	M10
12	Rubber-metal holder	50	50	30	M10
13	Rubber-metal holder	75	50	35	M12
14	Rubber-metal holder	90	50	35	M14
15	Rubber-metal holder	100	50	35	M16
16	Rubber-metal holder	100	60	35	M16
17	Rubber-metal holder	100	80	35	M16

We ship rubber-metal dampers with nuts, bolts and other parts.

Purpose: radiator holders, vibrating assemblies, AC holders,
vibrating rammers, vibrating tables, engline holders, exaustion pipe holders. ,nosači motora,nosači auspuha.

---

Rubber-metal holders (Rubber holder nut-nut)

No.	Name	A (mm)	B (mm)	C
1	Rubber-metal holder	30	20	M6
2	Rubber-metal holder	30	25	M6
3	Rubber-metal holder	30	30	M6
4	Rubber-metal holder	30	15	M8
5	Rubber-metal holder	30	20	M8
6	Rubber-metal holder	30	25	M8
7	Rubber-metal holder	30	30	M8
8	Rubber-metal holder	40	25	M8
9	Rubber-metal holder	40	30	M8
10	Rubber-metal holder	40	40	M8
11	Rubber-metal holder	50	50	M10
12	Rubber-metal holder	75	50	M12
13	Rubber-metal holder	90	50	M14
14	Rubber-metal holder	100	50	M16
15	Rubber-metal holder	100	60	M16
16	Rubber-metal holder	100	80	M16

We ship rubber-metal dampers with nuts, bolts and other parts.

Purpose: radiator holders, vibrating assemblies, AC holders, vibrating rammers, vibrating tables, engline holders, exaustion pipe holders.

---

Rubber metal foots
(Rubber metal foots for machine and other purpose)

No.	Name	A (mm)	B (mm)	C (mm)	D
1	Rubber metal foot	30	20	25	M6
2	Rubber metal foot	30	25	25	M6
3	Rubber metal foot	30	30	25	M6
4	Rubber metal foot	30	15	25	M8
5	Rubber metal foot	30	20	25	M8
6	Rubber metal foot	30	25	25	M8
7	Rubber metal foot	30	30	25	M8
8	Rubber metal foot	40	20	30	M8
8	Rubber metal foot	40	25	25	M8
10	Rubber metal foot	40	30	25	M8
11	Rubber metal foot	40	40	25	M8
12	Rubber metal foot	50	20	30	M12
13	Rubber metal foot	50	40	30	M10
14	Rubber metal foot	50	50	30	M10
15	Rubber metal foot	75	50	35	M12
16	Rubber metal foot	90	50	35	M14
17	Rubber metal foot	100	50	35	M16
18	Rubber metal foot	100	60	35	M16
19	Rubber metal foot	100	80	35	M16

We ship rubber-metal dampers with nuts, bolts and other parts.

This product is used for mounting on machines to reduce vibration and noise levels. It can also be used for other purposes. It is manufactured from 60 Sha black rubber.

Use: Legs for scales, bakery equipment and tables, washing machines.

---

Rubber metal plates (rings)

No.	Name	A (mm)	B (mm)	C (mm)
1	Rubber metal plates	30	20	6
2	Rubber metal plates	30	25	6
3	Rubber metal plates	30	30	6
4	Rubber metal plates	36	8	16.6
5	Rubber metal plates	30	15	8
6	Rubber metal plates	30	20	8
7	Rubber metal plates	30	25	8
8	Rubber metal plates	30	30	8
9	Rubber metal plates	40	25	8
10	Rubber metal plates	40	30	8
11	Rubber metal plates	40	40	8
12	Rubber metal plates	50	40	10
13	Rubber metal plates	50	50	10
14	Rubber metal plates	75	50	12
15	Rubber metal plates	90	50	14
16	Rubber metal plates	100	50	16
17	Rubber metal plates	100	60	16
18	Rubber metal plates	100	80	16

---

Rubber dampers

•
•
•
•

Click for large image

No.	Name	A (mm)	B (mm)	C (mm)
1	Rubber damper	30	20	6
2	Rubber damper	30	20	8
3	Rubber damper	30	25	8
4	Rubber damper	30	30	8
5	Rubber damper	40	40	10
6	Rubber damper	40	30	8
7	Rubber damper	40	25	8
8	Rubber damper	40	16	15
9	Rubber damper	40	30	10
10	Rubber damper	50	20	18
11	Rubber damper	50	40	10
12	Rubber damper	50	50	10
13	Rubber damper	60	30	16
14	Rubber damper	62	39	16
15	Rubber damper	70	25	15
16	Rubber damper	75	50	12
17	Rubber damper	80	80	20
18	Rubber damper	90	50	14
19	Rubber damper	100	50	16

Rubber fingers for plucking poultry are manufactured from black natural rubber of high elasticity. We offer pluckers for regular and fine plucking. The pluckers are manufactured in standard hardness of 55 Sha. There is also a possibility of shipping custom made pluckers.

---
